1.4. Menu structure
To enter the menu structure press and hold the Set/Reset button for longer than 10 seconds. The menu mode opens
with the password mode h=10. To unlock menu structure make h=18, use the (+) and (-) buttons. To go to the first
parameter press the Set/Reset button.
To change the parameter value, use the (+) and (-) buttons. To go to the next parameter press the Set/Reset button.
To save altered parameter settings, walk through the complete menu with the Set/Reset button until normal status
indication appears.
Timeout: When inside the menu structure the keys are untouched for 3 minutes, the system will switch back to the
normal status indication. Settings are not saved.
Menu structure
Status
parameter
Description Range
Factory
setting
h
Password protected
To unlock menu structure make h=18
10 - 99 h=10
C Heating max. flow temperature 25 - 90°C 82°C
C/r Modulation option
0 = Regulation on flow sensor (default)
1 = Regulation on return sensor or regulation on
system sensor
0
O Heating pump after run 1 - 25 min; CO=24uur 5 min
P Heating max input 45 - 100 % (fan 1800 – 5400 rpm) 100 %
A Boiler application
2=Standalone (for single boiler)
1=Slave (for TWIN right hand PCB)
0=Master (for TWIN left hand PCB)
2
H Type of application
00 = Adjustment for heating only
01 = Combi-boiler (with internal DHW tank)
02 = HWS storage cylinder 12kOhm (use for large
volume cylinders)
03 = HWS storage cylinder 10kOhm (use for large
volume cylinders)
04 = HWS storage cylinder 12kOhm (use for small
volume cylinders)
01
d (1) Setpoint temperature (Combi boiler) 40°C - 65°C 60°C
t (1) Hold temperature internal tank 40°C - 65°C 40°C
b (2) Setpoint temperature storage cylinder 25°C - 70°C 60°C
O/b (3) Basic temperature 10 - 90°C 40°C
O/S (3) Slope 01 - 99 20
O/d (3) Day reference temperature 10 - 90°C 40°C
O/t (3) Outdoor summer switch temperature 1 - 50°C 40°C
r
Return to “Factory setting”
Press (+) button for at least 5 seconds
Note: some settings do not return
= factory setting
= customised setting
u Configuration 0÷10V input
0 = Regulation on temperature
1 = Regulation on boiler output
0
o (4) Configuration of TWIN
01 = power mode (input 14,6 kW – 74,0 kW)
00 = comfort mode (input 7,3 kW – 74,0 kW)
01
F (2) Storage cylinder max flow temperature
65 - 90°C 85°C
S
Configuration pump
(2-stage pump regulation)
00 = automatic
= pump always high
= pump always low
00
Notes: (1) Active when H=1; (2) Active when H=2 or H=3 or H=4; (3) Active with outdoor sensor; (4) TWIN only
