Core E 400 User Manual

16
ADJUSTING THE LOWER HANDLE
The lower handle can be adjusted to
suit the operator.
1. Using a Torx
®
screwdriver (1), turn
the four handle clamp screws (2)
counter clockwise until the handle
(3) will rotate on the trimmer outer
shaft (4) (Fig. 1).
2. Slide the handle up or down (5)
and/or rotate it to a comfortable
position.
3. Re-tighten the handle clamp
screws to hold the handle in the
desired position.
NOTE: Do not over tighten the clamp
screws. You will break the clamp.
RELOADING THE BUMP HEAD WITH
TRIMMER LINE
The GasLess
TM
ELITE trimmer comes
preloaded with 16 ft of premium trimmer
line already installed. The trimmer line
has been designed to spin
aerodynamically, minimizing drag and
extending your Power Cells run time.
When the trimmer line is used up, you
will have to reload the bump head with
trimmer line.
WARNING: Avoid Injury! To
prevent accidental start up: Always
remove the Power Cell before
reloading the bump head.
1. Cut a length of line 12 to 16 feet
long.
2. Align the arrows on the head with
the eyelets. (Fig 2)
3. Thread one end of line into an
eyelet and push it through the head
and out the other eyelet.(Fig 3).
ASSEMBLY AND OPERATING
!
Fig. 1
Fig. 2
Fig. 3
