RELOADING THE BUMP HEAD WITH
TRIMMER LINE – cont’d
4. Pull both ends of the line until an
equal amount is extending from
both eyelets (Fig. 4).
5. Turn the knob clockwise until all but
6 inches of line are extending from
both sides of the trimmer head.
(Pull lightly on the line after every
6-8 clicks)
6. Cut the longer end so that both
strips are the same length.
7. Install a charged Power Cell and
begin trimming vegetation.
OPENING THE BUMP HEAD TO
RECOVER LINE
WARNING: Avoid Injury! To
avoid accidental start up: Always
remove the Power Cell before
removing or reinstalling the spool.
The trimmer line may break off at the
eyelet due to hitting debris. It may also
become entangled within the bump
head spool. In either case, you will have
to remove the spool from the bump
head as follows:
1. Press in the two tabs (Fig. 5).
To Next Page
