Core E 400 User Manual

18
OPENING THE BUMP HEAD TO
RECOVER LINE – cont’d
2. Gently twist the bump knob
clockwise to separate the two
halves, be careful not to lose the
spring (Fig. 6).
3. Remove any line from spool.
4. Use a clean rag to clean all debris
from the bump head shaft, inside
the bump head and from the spool.
NOTE: If the bump head and spool
are not properly cleaned, the bump
head will not work properly.
5. Align the two black tabs with the
opening in the main housing and
press together until both sides click
into place. Hint: Gently twist the
bump knob clockwise while
pressing together (Fig. 7).
6. Load trimmer line.
REMOVING THE BUMP HEAD
Your CORE GasLess trimmer is
supplied with an easy-to-bump, easy-to-
load trimmer head. Under normal use,
you should not need to remove this
trimmer head. If you find you need to
remove this head, then follow these
instructions.
ASSEMBLY AND OPERATING
Fig. 7
Fig. 6

Core E 400 Specifications

General

Brand	Core
Model	E 400
Category	Trimmer
Language	English
