EM 9250 Operator’s manual 105
UK
The rim surface must be perfectly clean to make the weight stick efficiently to the rim. If
necessary, clean the surface using suitable cleansing products.
18
•Manuallyappliedadhesiveweights
1 Select the first side to be balanced
2 Turn the wheel until the central element of the corresponding position indicator lights
up.
3 Apply the adhesive weight manually in the position in which the relative plane was
measured, using the centre of gravity of the weight itself as reference. In this phase,
one display shows the unbalance value of the side to be balanced and the other shows
the message "H.12" that indicates the correct
position of application as shown in figure 19.
WARNING
The machine allows the operator to select the
method for applying the CLIP adhesive weight at
6 o'clock (if the laser indicator is present) based
on his requirements.
To change the application position for the adhesive
weights, follow the instructions in the set up menu
"Adhesive weight application position ”.
•Manuallyappliedadhesiveweightswithlaser
device enabled (if provided)
1 Select the first side to be balanced.
2 Turn the wheel until the central element of
the corresponding position indicator lights up
together with the laser line.
19
