Cod. 4-118329D - 10/2017
English User Manual
Tel. ++39 0522 639.111 - Fax ++39 0522 639.150
www.corghi.com - info@corghi.com
Artiglio
Master Code

Table of Contents

Questions and Answers

  • M
    Mary FullerAug 20, 2025
    What to do if the Corghi Tyre Changer electricity supply fails with the MOUNT/DEMOUNT tool stuck?
    • D
      dbaldwinAug 20, 2025
      If the electricity supply fails with the MOUNT/DEMOUNT tool positioned between the rim and the tyre, try the following: Restart the machine without resetting it. If that doesn't work, use the bead breakers, operating them up and down, to create enough space to release the MOUNT/DEMOUNT tool from the tyre. As a last resort, manually release the wheel by inserting an 8 mm diameter steel pin in the hole and rotating anticlockwise.
  • S
    shane34Aug 22, 2025
    What does error E36 mean on my Corghi Tyre Changer?
    • J
      Jessica GibsonAug 22, 2025
      Error code E36 indicates that no wheel has been memorized. To resolve this, perform a scan.
  • N
    nguyenloriAug 25, 2025
    What does error E10 mean on my Corghi Tyre Changers?
    • J
      Jason CarterAug 25, 2025
      Error E10 indicates a horizontal-axis encoder time-out. You should restart the machine.
  • J
    John CookAug 26, 2025
    What does error E11 mean on my Corghi Tyre Changers?
    • M
      Michael BaxterAug 26, 2025
      Error E11 indicates a vertical-axis encoder time-out. Restart the machine to resolve this issue.
  • E
    Elizabeth FrancoAug 27, 2025
    What does error E161 mean on my Corghi Tyre Changer?
    • A
      Allison IngramAug 27, 2025
      Error E161 means the upper bead breaker position was not reached. Try restarting the machine.
  • A
    Alyssa RodriguezAug 30, 2025
    What does error E162 mean on my Corghi Tyre Changer?
    • A
      Amy MendozaAug 30, 2025
      Error E162 indicates that the lower bead breaker position was not reached. Restart the machine.
  • D
    Dawn CaseSep 1, 2025
    What does error E13 mean on my Corghi Tyre Changers?
    • W
      wayne38Sep 1, 2025
      Error E13 indicates a tool microswitch rotation issue. Try restarting the machine.
  • C
    Christopher MeyerSep 3, 2025
    What does error E34 mean on my Corghi Tyre Changers?
    • L
      Laura HernandezSep 3, 2025
      Error E34 indicates that the micro end stroke tool is concurrently active. To resolve this, restart the machine.
  • Y
    yvettegilbertSep 5, 2025
    What to do if Corghi Tyre Changer displays error E38?
    • T
      Theresa BruceSep 5, 2025
      Error E38 indicates a reading failure. Repeat the command to try again.
  • C
    Christopher JenkinsSep 7, 2025
    What does error E160 mean on my Corghi Tyre Changer?
    • A
      Ariana CuevasSep 7, 2025
      Error E160 indicates that the horizontal axis microswitch is pressed. Release it manually or de-ice it.

Summary

1. GETTING STARTED

1.2 Safety Information

Details hazard definitions and general safety warnings for machine operation.

1.2.a General Warning and Instructions

Crucial warnings and instructions for safe operation and accident prevention.

1.2.c Electrical and Pneumatic Connections

Provides guidance on electrical hook-up and pneumatic connections for safe operation.

1.5 Employee Training

1.6 Pre-Use Checks

Details pre-operation checks to ensure machine components are in good condition.

1.7 During Use

2. TRANSPORT, STORAGE AND HANDLING

3. HOISTING;HANDLING AND INSTALLATION

3.1 Installation

Provides step-by-step instructions for assembling the filter unit, motor guard, and covers.

3.2 Installation Clearances

4. ARTIGLIO MASTER CODE DESCRIPTION

4.2 Equipment Components (Main Working Elements)

4.3 Controls

5. BASIC PROCEDURES - USE

5.1 Turning the Machine On

5.2 Preliminary Checks

5.3 Loading and Clamping the Wheel

Step-by-step guide for loading and securely clamping a wheel onto the turntable.

5.4 Automatic Work Procedure

Introduces the machine's automatic operation modes for tyre changing.

Bead Breaking - Demounting

Provides warnings and steps for bead breaking and tyre demounting.

Mounting

Warnings and initial steps for tyre mounting.

5.5 Manual Work Procedure

Outlines manual procedures for tyre changing operations.

5.7 Tyre Inflation

Covers tyre inflation procedures and safety considerations.

5.8 Unclamping and Unloading the Wheel

7. MAINTENANCE

Scheduled Maintenance

8. TROUBLESHOOTING

Errors List

WIRING DIAGRAM

PNEUMATIC DIAGRAM

Corghi Artiglio Master Code Specifications

General IconGeneral
BrandCorghi
ModelArtiglio Master Code
