Artiglio Master Code User Manual 31
UK
1 - Temperature measuring sensor (see the section OPTIONAL ACCESSORIES)
2 - Rim diameter manual configuration keys
They consist of:
- Large arrows
- Small arrows
3 - Display showing the rim diameter and user interface
4 - Key for configuring rim diameter
5 - Tread thickness measuring sensor (see the section OPTIONAL ACCESSORIES)
6 - Automatic procedure keys
They consist of:
-NORMAL normal tyre mounting/demounting
-RFT-UHP: mounting/demounting of Runflat (RFT) tyres, tyres with lower shoulder and
racing tyres (UHP)
-SOFT: mounting/demounting of off-road vehicle tyres, or tyres with soft sides
7 - Last wheel call-up key
8 - Menu key
9 - Help online key
10 - Inflatron (see the section OPTIONAL ACCESSORIES)
11 - Tpms (see the section OPTIONAL ACCESSORIES)
12 - Camera (see the section OPTIONAL ACCESSORIES)
4.3.e. PRESSURE GAUGE WITH DEFLA-
TION BUTTON (Fig. 22)
1 - Air pressure display
pressure gauge
Regulated by pedal
2 - Deflation button
4.4. OPTIONAL ACCESSORIES
For a complete list of optional accessories supplied on request, see the document “ORIGI-
NAL ACCESSORIES FOR THE ARTIGLIO MASTER CODE TYRE CHANGER”.
1
22
2
