4.2. EQUIPMENT COMPONENTS
(MAIN WORKING ELEMENTS OF THE MACHINE) - FIG. 17
6a
6
8
9
10
17
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
24
25
23
1 Operating console
2 TPMS (optional)
3 Inflatron (optional)
4 Touch screen display for machine func-
tions
5 Upper bead breaker disc
6 Lever to unlock the upper bead breaker
disc
6a Lever to position the upper bead
breaker disc
7 Lower bead breaker disc
8 Fixed tool
