Corghi Artiglio Master Code - Inflating Tyres

Artiglio Master Code User Manual 69
UK
During this operation, noise levels assessed at 85 dB(A) may occur.
Operators are advised to wear hearing protection devices.
5.7.b. INFLATING TYRES
1. Make sure the wheel on which the tyre is fitted is securely
clamped on the turntable by the centring handle (Fig. 48).
2. Make sure the tool head, upper and lower bead break-
ing units and bead depressor are not near the work area,
and if possible are in the rest position (see Figs. 48 a-b-c).
3. Remove the valve stem core if not already done (Fig.
48d).
4. Connect the air hose
Doyfe inflator chuck to the
valve stem (Fig. 48e).
5. Press
to inflate the
tyre. The tyre will expand,
and the beads will seat.
48
48d 48e
48c
48a
48b
WARNING
WARNING
