Corghi Artiglio Master Code - 6 Optional Accessories; Inflatron

Artiglio Master Code User Manual 87
UK
6. OPTIONAL ACCESSORIES
6.1. INFLATRON
From the main screen (Fig. 71) press the key
The Inflatron inflator is an electronic precision
instrument to automatically inflate and deflate
vehicle tyres (see section 1.4 INTENDED USE OF
THE MACHINE).
Correct use enables the operator to optimise operating stages and save time, and carry
out other operations with maximum time savings.
Intended operating conditions
Inflatron has been designed exclusively for inflating and deflating tyres, using the tools
with which it is equipped as described in this manual. Any other use is inappropriate.
Technical specifications
- Operating pressure………………………8-10 bar
- Power supply………………………………24Vdc
- Noise level in working conditions………..< 70dB(A)
Main working elements of the machine
Learn the set up of all controls and their functions. Carefully check that all controls
on the device are working properly. The device must be installed properly, operated
correctly and serviced regularly in order to prevent accidents and injuries.
1 Automatic cycle start key
2 Automatic cycle “STOP” key
3 Overpressure key
4 INFLATRON exit key
5 Inflation pressure configured
6 Arrow key to increase pressure
7 Arrow key to decrease pressure
8 Overpressure flashing indicator
9 Configured pressure indicator
10 Pressure unit of measurement (bar
- PSI - KPa)
WARNING
1
2
34
5
6
7
8
9
10
72
71
