Corinex AV200 - 5 Network Configuration; 5.1 Setting an IP Address on your Computer; 5.1.1 Setting Up a Static IP in Windows XP

34
Network Configuration
Corinex AV200 Powerline Ethernet Wall Mount F
2. Select the Local Area Connection icon for the applicable adapter (Ethernet
adapter or Powerline - usually the first adapter listed). Double-click the Local
Area Connection.
3. The Local Area Connection Status screen will appear. Click Properties.
5 Network Configuration
5.1 Setting an IP Address on your Computer
This section explains how to set a static IP on your computer, in order to connect to
the Corinex AV200 Powerline Ethernet Wall Mount F and configure it.
5.1.1 Setting Up a Static IP in Windows XP
1. Click the Start button, open the Control Panel. From there, click the
Network Connections icon and then the Network Connections window
appears.
