Appendix A—Model Number Identification Code
Models D51 and F51
Appendices
A. Model Number Identification Code and Available Options
Base Model # D51 F51
Inlet 1" NPT 1" NPT
Outlet 3/4" NPT 3/4" NPT
Weight bare
pump lbs. (kg)
40 (18.1) 25 (11.3)
Specification Fields
Pump Iron Standard A
Vanes Carbon Standard D
O-ring Material
Buna-N Standard A
Neoprene
®1
No charge option B
Seal Seat
Material
Silicon carbide Standard 6
Mounting Options
Part Number
Model
Reference
Maximum
Motor Frame
Size
Ship Weight
lb (kg)
Mounting Only
Mounting Option
101-12 F51 only 145T 25 (11.3)
Mounting for frame mounted pump
(F51) mounting includes steel
baseplate and direct drive through
flexible coupling.
1
Registered trademark of the DuPont company.
Product Description
D51 Bare pump with mounting bracket and flexible coupling to close couple the pump to any NEMA 56 or 66 C-face
motor (Note motor is not included).
F51 Frame mounted pump for baseplate mounting (bare pump only).
14
Model Number
Base X X X X
