Appendix D—Outline Dimensions for Models F1021
All dimensions are in inches (centimeters).
Model A B C D E F G H J K L M N P Q
F1021 3 2-/12
7-3/4
(19.70)
5-1/2
(14.00)
2
(5.10)
1-3/4
(4.40)
2-5/8
(6.70)
3-1/2
(8.90)
8-1/2
(21.60)
6-1/2
(16.50)
4-1/8
(10.50)
4-15/16
(12.50)
1/4
(0.64)
1-1/8
(2.90)
1/2
(1.27)
