Series 65-80
42
bucket has lowered to the correct height from the
ground.
Floating (auto-levelling): the auto-loading tool
may also be used to function as an auto-levelling
device, useful, for example for levelling ground. To
block the bucket in the floating position you must
push the auto-loading lever forward past the lowering
position until you have heard a click (the lever
remains in stable position).
CAREFUL: During the driving an
of the machine, the self-
not remain the the floating position.
3.11. SUPPLEMENTARY HYDRAULIC COMMAND
Some versions may be equipped with a hydraulic
force instrument for the command of auxiliary
equipment.
The hydraulic force instrument is composed of two
openings with rapid transmission of standard type,
indicated by the letters “A” and “B”, situated on the right
side of the dashboard.
To obtain hydraulic oil pressure on the openings you
must work the auxiliary command lever.
To obtain pressure on the “A” opening, push the lever
forward.
To obtain pressure on the “B” opening, pull the lever
backward, toward yourself.
READ CAREFULLY: Read the user’s
instructions carefully for all accessories
and/or tools that have been installed on
your machine. Always refer to the manual
which was provided with them and always
keep it attached to this manual.
3.12. ACCESSORIES
Your machine can
be equipped with
some additional
devices that make it
more complete.
To the side is
shown the position of
the 12V DC power
outlet (see fig. 58)
that provides power
for operation of
fig. 58 - DC- out
