Series 65-80
6
piston;
• slowly lower the unit with the motor off until the
correct fit of the device is obtained.
Afterwards remove the device and put it back in its slot.
1.6.2. B
LOCKING THE
A
RM
If necessary, the machine is equipped with a device
used to block the down-loading arm in the raised
position and prevents accidental lowering, as needed
can be placed on the piston on the left or right in a
similar manner.
Follow these steps (see fig. 2):
• Raise your arm of self-loading;
• Lift the body;
• Turn off the engine;
• Remove the safety device “E”, on the left side of the
container from the housing by loosening the knob “F”;
• Enter the slots of the bar near one of the two pistons of
hydraulic cylinders of the arm;
• Turn the bar and placed it parallel to the piston;
• Pull down slowly, with the engine off, the arm until the
frame of the device.
After the operations, remove the device and place it
back into place.
1.6.3. B
LOCKING THE
F
OOTREST
The drive footrest must always be blocked in open
position, during the work, to prevent its accidental
movement, by using the safety pin “C” (see fig.2).
Introduce pin “C” into hole “1” to block the footrest in the
raised position;
Introduce pin “C” in hole “2” to block the footrest in the
lowered position;
CAUTION: Always use the drive footrest
in open position during the work, to
prevent risks.
only after use.
1.6.4. B
LOCKING THE
L
IFT
(“H
I
-T
IP
”)
The raising device for the body for high
unloading (Hi-Tip) can be blocked in a raised
position to impede accidental movement, by using
the safety pin “D” (see fig. 2).
Introduce the pin in the hole to block the mechanism in
the raised position.
