Series 65-80
48
4.2. MOTOR
READ CAREFULLY: Carefully read the
instructions and the mode of use for the
motor found in the attached specific manual.
The machine that was delivered could be equipped at
the origin with different engine types for specific needs
and/or markets.
A correct maintenance is the best way to conserve the
motor of your machine so that it is always working at its
highest efficiency and this allows you to maintain low
operation costs.
For the maintenance of the motor, pay scrupulous
attention to the attached manual that was given to you.
REQUIRED: When changing the motor oil,
always use a suitable aspirator to remove old
oil.
Avoid the dispersion of oil and filters in the
environment and carry out their disposal with
respect for the environment and the
regulations in force.
4.2.1. PRE-FILTER AND AIR FILTER IN AN OIL BATH
Your machine can be equipped with a special air filter in
an oil bath, which increases and improves the filtration
capacity.
The maintenance
of pre-filter “P” (see
fig. 67), establish the
cleaning every 100
hours.
Unscrewing the
wing screw (see fig.
68), which blocks the
cover of pre-filter,
remove the section in
clear plastic “T”,
clean using a simple
washing with water
and then replace il.
For the mainte-
nance of the filter in
an oil bath “F”, is
necessary remove the engine hood.
After removing the hood, the air filter is easily
accessible.
fig. 67
Pre-filter and Air Filter
