ICE CUBER SPECIFICATION – 60 HERTZ
MODEL IRC1448 IRC1448-3PH IRC2448 IRC2448-3PH
UNIT
Volts 230 230 230 230
Phase 1 3 1 3
Hertz 60 60 60 60
No. Wires 2+ground 3+ground 2+ground 3+ground
MIN. CIRCUIT
Amps 25 25 30 25
MAX FUSE SIZE (HVAC CIRCUIT BREAKER REQUIRED)
Amps 25 25 30 25
REFRIGERANT
Type R404a(HP 62) R404a(HP 62) R404a(HP 62) R404a(HP 62)
Weight (oz) 250 250 320 320
Weight (g) 7088 7088 9072 9072
COMPRESSOR
Volts 230 230 230 230
Phase 1 3 1 3
Hertz 60 60 60 60
LRA 95.6 82 125 90
RLA 23.9 10 20 13
CONDENSER FAN MOTOR (AIR COOLED SYSTEMS ONLY
AIR CIRCULATION FAN MOTOR (WATER-COOLED & REMOTE SYSTEMS ONLY)
Volts 230 230 230 230
Phase 1 1 1 1
Hertz 60 60 60 60
Amps Running 0.36 0.36
Watts 6 6W
WATER PUMP
Volts 230 230 230 230
Phase 1 1 1 1
Hertz 60 60 60 60
Amps Running 0.5 0.5 0.77 0.77
HP 1/30 1/30 1/50 1/50
