4-42
Section 4
Aft Seat Bottom Cushion
The aft seat bottom cushion can be removed by releasing the port
and starboard rubber latches. The latches are the same used on the
inside of the engine box cover. The seat cushion can then be lifted
out of the boat and stored under the bow.
Walk-Thru Windshield Opening/Latching
(optional on 196)
There are two latches on the inside starboard side of the walk-thru
windshield. Rotate both of the window locks (A) to secure or unlock
the window. Always have window closed and secured when
trailering the boat.
An open window can cause death or
serious injury. Make sure both window locks are secure
when vessel is in motion.
