CORRECT CRAFT Boat - Optional Dash Pod and Console

3-6
Section 3
Optional Dash Pod and Console
1. Digital Stereo Remote w/Clock
2. Tachometer
3. Nautique Cruise
4. Check Engine Light
5. Speedometer
6. Service Soon Light (catanium engine only)
7. Oil
8. Fuel
9. Engine Temperature Gauge
10. Voltage Gauge
11. Ignition and Switch Panel – refer to Ignition and Switch Panel in
this section
12. 12-Volt Port
13. Shifter/Throttle Control Handle
14. Shift Lock-Out Umbrella
15. Neutral Warm-Up Button
16. Ballast Tank(s) Level – not shown, 216 only
17. Emergency Stop Switch
18. Automatic Bilge Panel – not shown
19. Steering Wheel Tilt Lever
NOTICE
A full description of the gauges and switches and their functions is
discussed in Section 4, Dash Pod — Limited or Team.
12V
12V
CORC082
6
17
18
16
14
15
13
12
11
10
9
8
7
5
4
3
2
1
19
