4-45
Controls and Indicators
Engine Cooling Water Intake Valve
Your boat is equipped with a valve (seacock) on the engine cooling
water intake. The handle has a slide mechanism to prevent the
valve from being shut off inadvertently. The valve is used to shut off
the water supply in the event a hose failure or water leakage occurs.
The valve is open when the yellow handle is in-line with the valve
body and the valve is closed when the handle is perpendicular to
the valve body. Leave the valve open at all times unless an
emergency condition requires you to close the valve to stop a leak
or the possibility of a leak. The valve is located on the starboard side
of the transmission.
Battery Disconnect Switch (optional)
The battery disconnect switch allows you to isolate all power to the
boat. This switch provides positive disconnect of the battery to
protect against tampering, electrical fire hazards and battery
rundown. Rotate the switch to the OFF position when the boat is
not in use.
