CORRECT CRAFT Boat - Optional Ignition and Switch Panel

3-7
Optional Ignition and Switch
Panel
1. Keyless Ignition Key Pad
2. Port Ballast – Optional, 216 only
3. Starboard Ballast – Optional, 216 only
4. Underwater Lights
5. Heater Fan
6. Courtesy Lights/Docking Lights
7. Navigation Lights/Anchor Light
8. Bilge Pump(s)
9. Engine Compartment/Bilge Area Blower
10. Horn
11. System Indicator Light
12. Ignition Indicator Light
NOTICE
If your boat is not equipped with the features on the Ignition and
Switch Panel Switch buttons, the button will not have a function.
A full description of the key pad keys and switch buttons and their
functions is discussed in Section 4, Dash Pod — Limited or
Team, Switches.
START
CORC083A
1
2
3
4
5
6
8
9
10
7
11
12
196, 206 and 216
