3-5
196, 206 and 216
Standard Dash Pod and
Console
1. Ignition Switch
2. Tachometer
3. Nautique Cruise
4. Check Engine Light
5. Speedometer
6. Service Soon Light (catanium engine only)
7. Oil
8. Fuel
9. Engine Temperature Gauge
10. Voltage Gauge
11. Engine Compartment/Bilge Area Blower Switch
12. Navigation/Anchor Light Switch
13. Bilge Pump(s) Switch
14. Horn Switch
15. 12-Volt Port
16. Heater Switch (optional)
17. Shifter/Throttle Control Handle
18. Shift Lock-Out Umbrella
19. Neutral Warm-Up Button
20. Ballast Tank(s) Level (optional) – not shown, 216 only
21. Emergency Stop Switch
22. Steering Wheel Tilt Lever
Keys
23. Fuel Tank Fill Cap Key
24. Hatch Latch Key
NOTICE
A full description of the gauges and switches and their functions is
discussed in Section 4, Standard Dash Pod.
