Description
1. Bow Navigation Light
2. Bow Lifting Ring
3. Standard Speedometer Calibration Adjustment
(under deck near driver’s right knee)
4. Dash Pod
5. Console
6. Engine Cover
7. Propeller Shaft Stuffing Box
8. Fuel Tank Fill
9. Bilge Pump Outlet
10. Storage Trunk
11. Stern Lifting Ring
12. Boarding Platform
13. Anchor Light Receptacle
14. Rudder Shaft Remote Lube Fitting
(optional)
15. Fuel Tank Vent
16. Engine Cooling Water Intake Shutoff Valve
17. Engine Cooling Water Strainer
18. Anchor Light Storage
19. Watersports Tow Point
20. Floor Cooler w/Removable Tray
21. Love Seat/Bow Storage Access
22. Operator’s Seat Adjustment
23. Dry Storage Only
24. Glove Box/Stereo/Auxiliary Input/12V Port
NOTICE
The battery is located in the floor, in front of the in-floor cooler.
