Corsair Hydro Series User Manual

For LGA 115X installation, slide the backplate pins inside (figure 1).
For LGA 1366 installation, slide the backplate pins outside (figure 1).
Install the assembled backplate (figure 2).
Note: Intel LGA 2011 and LGA 2066 does not require backplate installation. Proceed to step 2.
Installing the Intel Standof Screws
Attach the provided Intel standof.
Use (B) for LGA 115X / 1366, or (C) for LGA 2011 / 2011-3 / 2066.
Tighten all four screws until firmly secure.

Corsair Hydro Series Specifications

General

Type	Liquid CPU Cooler
Radiator Size	120mm, 240mm, 280mm, 360mm
Compatibility	Intel LGA 115x, 1200, 1700, 2011, 2066; AMD AM4
Noise Level	10 - 36 dB
Warranty	5 years
Fan Speed	600 - 2400 RPM
