Chapter 2 Hardware Configuration
This chapter provides all the necessary information for installing the Q35SB into a standard PC
chassis. Topics discussed include: installing the processor, DRAM and jumper settings.
Handling Precautions
The Q35SB has been designed to be as rugged as possible but it can be damaged if dropped, jarred
sharply or struck. Damage may also occur by using excessive force in performing certain installation
procedures such as forcing the system board into the chassis or placing too much torque on a
mounting screw.
Take special care when installing or removing the system memory DIMMs. Never force a DIMM into
a socket. Screwdrivers slipping off a screw and scraping the board can break a trace or component
leads, rendering the board unusable. Always handle the Q35SB with care.
Special Warranty Note:
Products returned for warranty repair will be inspected for damage caused by
improper installation and misuse as described in the previous section and the static
warning below. Should the board show signs of abuse, the warranty will become void
and the customer will be billed for all repairs and shipping and handling costs.
Static Warning
The Q35SB contains delicate electronic semiconductors that are highly sensitive to static electricity.
These components, if subjected to a static electricity discharge, can be weakened thereby reducing
the serviceable life of the system board. BEFORE THE BOARD IS REMOVED FROM ITS
PROTECTIVE ANTISTATIC PACKAGING, TAKE PROPER PRECAUTIONS! Work on a conductive
surface that is connected to the ground. Before touching any electronic device, ground yourself by
touching an unpainted metal object or, and highly recommended, use a grounding strap.
