Chapter 1 Technical Specifications
The Q35SB is a long-life industrial motherboard with multi-core processor technology and PCI
Express support (internal). Powered by the Intel® Q35 Express chipset, the Q35SB motherboard
was designed specifically for performance intensive embedded applications such as Medical,
Security, Imaging, Industrial Automation, and Manufacturing, or any application that could benefit
from a PICMG back-plane solution. This platform adds support for the new Intel 45nm processors.
Embedded Processor (775 LGA package)
Intel® Core™ 2 Quad Q9400 6M cache, 2.66GHz, 1333 MHz FSB, 45nm
Intel® Core™ 2 Duo E8400 6M cache, 3.00GHz, 1333 MHz FSB, 45nm
Intel® Core™ 2 Duo E7400 3M cache, 2.80GHz, 1066 MHz FSB, 45nm
Intel® Core™ 2 Duo E6400 2M cache, 2.13GHz, 1066 MHz FSB, 65nm
Intel® Core™ 2 Duo E5300 2M cache, 2.60GHz, 800 MHz FSB, 45nm
Intel® Core™ 2 Duo E4300 2M cache, 1.80GHz, 800 MHz FSB, 65nm
Intel® Dual Core™ E2160 1M cache, 1.80GHz, 800 MHz FSB, 65nm
Intel® Celeron E1500 512K cache, 2.20GHz, 800 MHz FSB, 45nm
Intel® Celeron 440 512K cache, 2.00GHz, 800 MHz FSB, 65nm
Non-Embedded Processors
For additional supported processors, please contact your Sales Representative.
Chipset
Intel® Core 2 Duo, Wolfdale and Conroe L support
Supports FSB of 800/1066/1333 MHz
Intel® Integrated Graphics Accelerator 3100
(GMA3100) with CRT.
Analog video maximum resolution 2048x1536@75
Hz refresh
Two sockets of DDR2 memory @ 667/800MHz
(4GB max memory size)
ACPI 1.0 Power Management
Q35 GMCH
1226 BGA package
7
