Removing Harness System
15
Only remove the harness system to clean the seat pad.
1. Fully Loosen Harness
Straps
3. Turn Seat Over
Locate harness straps’ metal
retainers on bottom of shell.
2. From Back, Remove
Harness Strap Loops
From Splitter Plate
continued on next page
4. Using a Flathead
Screwdriver, Lift Metal
Retainer Off of Tab
Repeat for other side.
7. Rotate Metal Retainer
and Push It Up Through
Shell and Pad
5. Push Metal Retainer
Up Through Shell and
Pad As Shown
Repeat for other side.
6. Locate Buckle’s Metal
Retainer on Bottom of
Shell
