XXXXX XXXXX
Harness System Adjustment for
Smaller Infants
9
4. Replace Pad and
Check Buckle
Pull up on buckle to make sure it
is secured.
The buckle
MUST not pull out.
1. With Buckle in the
1st Slot As Shown,
Turn the Seat Over
If you need to move the buckle to
the 1st slot, see page 5.
5. Turn Seat Over
Locate harness straps’ metal
retainers on bottom of shell.
6. Using a Flathead
Screwdriver, Lift
Metal Retainer Off
of Tab
Repeat for other side.
7. Pull Metal Retainer
Towards You and
Out of Its Original
Location
Repeat for other side.
2. From Bottom of
Seat, Pull Metal
Retainer Towards You
and Push It Up into
Middle Slot As Shown
3. From Top of Seat, Lift
Pad Up and Lay the
Metal Retainer Flat
Against the Shell As
Shown
If you will be using the
lowest shoulder harness
slots, you
MUST adjust the
harness straps.
continued on next page
