12
XXXXX XXXXX
11
9. Fully Loosen Harness
Straps
10. From Back, Remove
Harness Strap Loops
From Splitter Plate
11. Pull Harness Straps
Out of Shoulder
Harness Slots
12. Rethread Harness
Straps into Lowest
Shoulder Harness
Slots
13. Attach Harness Strap
Loops to Splitter Plate
As Shown
Sewn ends of the harness strap
loops
MUST face towards you.
DO NOT twist harness straps or
harness adjustment strap.
Make sure the harness strap loops
are fi tted COMPLETELY ON both
sides of the splitter plate.
8. Push Metal Retainer
Up into Slot on Bottom
of Shell As Shown
Repeat for other side.
From the front, pull on harness
straps to make sure the retainers
do not pull out.
WARNINGS: Harness system must be installed
correctly.
Failure to follow these steps can result in serious injury or
death.
