18
XXXXX XXXXX
Removing Seat Pad for Cleaning
17
9. Pull Harness System
Completely Out of
the Shell and Pad
8. From Top of Seat,
Pull Buckle Out of Shell
Remove Pad
Pull pad off the top of the child
restraint and remove pad.
You must remove the harness system to remove the pad
from the shell. See pages 15-17.
To remove accessories, see page 22.
WARNINGS: Do not use child restraint without the seat
pad.
Failure to do this can result in serious injury or death.
Cleaning Pad and Accessories
Machine wash all pieces separately with cold water on a gentle
cycle. Do not use bleach. Tumble dry separately for 10-12
minutes on low heat. Remove immediately.
Cleaning Harness Straps
Spot clean using warm sudsy water and damp cloth.
Replace Pad
Starting from bottom of child restraint, slip pad on shell. Pull
harness adjustment strap through pad. Wrap pad around the
top of shell. Install harness system, see pages 19-21.
