Use this method only if local codes permit connecting ground conductor to
neutral supply wire.
WARNING
Electrical Shock Hazard
Frame grounded to neutral of appliance through a link
Grounding through the neutral conductor is prohibited for new branch-
circuit installations (1996 NEC); mobile homes; and recreational vehicles, or
in an area where local codes prohibit grounding through the neutral
conductor. For installations where grounding through the neutral
conductor is prohibited, see the Ungrounded Neutral graphic.
Disconnect the ground from the neutral at free end of conduit. Use
grounding terminal or lead to ground unit.
Connect neutral terminal or lead to branch circuit neutral in usual manner.
Failure to do so could result in death, fire or electric shock.
4. Feed the flexible conduit through the conduit connector, and tighten
strain relief screw against the flexible conduit.
5. Complete installation following instructions for your type of electrical
connection:
• 4-wire (recommended)
• 3-Wire (if 4-wire is not available)
3-Wire Connection: Direct Wire
1. Connect the GROUND (green) wire the NEUTRAL (white) wire from the
oven to the branch circuit NEUTRAL (gray or white) wire.
2. Connect the red and black leads from the oven to the corresponding
leads in the junction box.
