Ungrounded Neutral
GAS CONNECTION
a
b
c
g
f
e
h
d
Junction Box
Red Wires
Green Wires
Cable from Oven
UL Listed Conduit
Connector
Black Wires
White Wires
Cable from Power
Supply
a
b
c
d
e
g
h
f
Explosion Hazard
Use a new CSA International approved gas supply line.
Install a shut-off valve.
Securely tighten all gas connections.
If connected to LP, have a qualified person make sure gas pressure does
not exceed the maximum pressure listed in the "Gas Supply Requirement"
section.
Examples of a qualified person include:
• licensed heating personnel
• authorized gas company personnel
• authorized service personnel
Failure to do so can result in death, explosion or fire.
WARNING
To Next Page
