24
commands
0x16
RESTORE_USE
R_ALL
W-E
1
Reset to Default
0x20
VOUT_MODE
RO
1
Use linear format mode, may vary from
different model, N=-8 (1/256v), used by all
commands related to output voltage
0x21
VOUT_COMMA
ND
R/W-E
2
linear format, 0x6400 for 100v model,
based on VOUT_MODE exponent
0x78
STATUS_BYTE
RO
1
Summary of most critical faults
0x79
STATUS_
WORD
RO
2
Summary of unit’s fault condition
0x88
READ_VIN
RO
2
linear format
0x8B
READ_VOUT
RO
2
linear format
0X8C
READ_IOUT
RO
2
linear format
0X8D
READ_TEMPER
ATURE_1
RO
2
linear format, °C
0X8E
READ_TEMPER
ATURE_2
RO
2
linear format, °C
0X8F
READ_TEMPER
ATURE_3
RO
2
linear format, °C
0X90
READ_FAN_SP
EED_1
RO
2
linear format, RPM
0X98
PMBUS_
REVISION
RO
1
0x00
0X99
MFR_ID
RO
16
Write protected
0X9A
MFR_MODEL
RO
16
Write protected
