25
0X9B
MFR_REVISION
RO
16
Write protected
0X9C
MFR_
LOCATION
RO
16
Write protected
0X9D
MFR_DATE
RO
16
Write protected
0X9E
MFR_SERIAL
RO
16
Write protected
0XD0
Operation Mode
R/W-E
1
Write protected
0:local mode 1:remote mode
0XD1
SLAVE ID
R/W-E
1
Write protected
Device ID for PMBUS
0XD2
Power soft start
R/W-E
2
50
Write protected 50~1000 ms
0XD3
SV soft start
R/W-E
2
6
Write protected 50~1000 ms
0XD5
SI soft start
R/W-E
2
60
Write protected 50~1000 ms
0XD6
Power on rule
R/W-E
1
0
Write protected 0~2
0XD7
Current setting
R/W-E
2
Write protected
0XD8
Multi/Single
R/W-E
1
0
0:single 1:multi
0XD9
CAN with ID
R/W-E
1
0
0:CAN ID Check 1:CAN ID without Check
STATUS_BYTE (0x78)
This command returns an abbreviated status for fast reads.
Bit #
Status Bit Name
Description
7
Not Used
6
Not Used
5
VOUT_OV_FAULT
An output overvoltage fault has occurred
4
IOUT_OC_FAULT
An output over current fault has occurred
3
VIN_UV_FAULT
An input over voltage fault has occurred
