Cotek AD-1500 - Page 37

34
10
1024
Vafter Over voltage protection
OVP FAIL
11
2048
Vrmt Over voltage protection
OVP FAIL
12
4096
Vcap Over voltage protection
OVP FAIL
13
8192
FAN_FAIL (F_Err)
FAN FAIL
14
16384
EEPROM Fail
OVP FAIL
Ref.5
STUS
Status of output
0
power off
1
power on
REMS =1 , "1" = Enable , "0" = Disable , if EN+&- is 1=ON
0
Time sequence
1
2
3
4
OR
CMD (POWER)
0
1
0
1
(Parallel
Connection)
EN+&-
0
0
1
1
Output status
OFF
ON
ON
ON
When REMS =0 , CMD will not function, no matter if
Power 0/1
1
Time sequence
1
2
3
4
Ref.6
AND
CMD (POWER)
0
1
0
1
(Series
Connection)
EN+&-
0
0
1
1
Output status
OFF
OFF
OFF
ON
REMS =1 , "1" = Enable , "0" = Disable , if EN+&- is
1=ON
2
REMS =1 , "1" = Enable , "0" = Disable , if EN+&- is 1=ON
