35
Time sequence
1
2
3
4
CMD (POWER)
0
1
0
1
EN+&-(don’t care)
0
0
1
1
Output status
OFF
ON
OFF
ON
When REMS =0 , CMD will not function, no matter if Power
0/1
Ref.7
ERR3?
bit
Decimal
ERROR Content
LED State
0
1
Different TYPE
1
2
SAME ID
2
4
CANBUS Communication fail
3
8
Slave error
4
16
REV.
IDALL?
Ref.8
byte
description
0
M :Master S:Slave O:Single
1
, comma
2~12
Serial Number (11 characters)
