4-5-1 Connecting D11 to the CANBUS
This section describes how to connect D11 to the CANBUS. It will be
assumed that the D11 is located at the start /end of the CANBUS.
Please observe the termination of your CANBUS.
4-5-2 Connecting D11 to the Ethernet Network
D11 has an integrated network terminal. This allows you to connect D1
to a 10/100M Bit Ethernet network. The speed is switched automatically using
the connected switch, router or PC.
Connecting D11 within a local network
Connecting D11 directly to PC
