6
3. Instructions
S150, S300 and S500 series are very reliable, portable, and fully protected.
These pure sine inverters are used in a wide range of applications such as
vehicles, office equipment, home entertainment, electronic appliances, etc.
To have the most effective power inverter performance, it must be installed
and used properly. Please read the instructions of this manual before you
install and operate this model.
3-1. Front Panel Introduction
S150/300 Front Panel S500 Front Panel
Model
S150 / S300 / S500
˕
A
AC output socket
˕
B
Main switch
˕
C
Remote port
˕
D
Power status LED
3-1-1. AC output (Outlet Sockets available) ˕
A
