Repair Parts 13
Ref. Description Qty. CL520CT7
1A Pressure Regulator 1 FPAPR
2 Pressure Gauge 1 TC2104
3 3/4” NPT x 1” Hose Barb 90° Elbow 1 U78-770P
4 1” Hose Clamp 2 U19-55SS
5 1” Hose 1 U74-37R
6 3/4” NPT x 1” Hose Barb Adapter 1 24206A004
7 3/4” NPT x 3/4” NPT x 3/4” NPT Street Tee 1 05002A001
8 5/16”-18 Flanged Nuts 6 U36-202BT
9 Tank Flange 1 U31-442P
Tank Bladder 1 U20-7
10 Tank Body 1 *
11 Air Valve with Cap 1 U212-160
* If tank body fails, replace entire tank (Part Number RT6H).
• Not illustrated.
1A
2
1B
1C
1D
2
3
4
4
6
7
8
9
10
11
5
6087 0909
Model 561474-01
Model 312242-01
