Coway P-220R - Disassembling the Top-Cover Assembly

Disassembling and refitting
Coway co., Ltd
4-3
No. Part names Description Reference picture
2 T
op-Cover
Assembly
3)
Separate the Main Tank-Cap
Assembly by pulling it in the
direction of the arrow as shown
in the figure.
4) Separate the Antibacterial Filter
by pulling it in the direction of the
arrow as shown in the figure.
3 Front-Cover
Assembly
1)
Remove the 2 screws from the
Front-Cover Assembly.
: 2-THT 4X12
2) Separate the Front-Cover
Assembly by pulling it in the
direction of the arrow as shown
in the figure.
