Coway P-220R - 4-2-6 Disassembling the Feed Nos-Valve Assembly

Disassembling and refitting
4-12
Coway co., Ltd
4-2-6 Disassembling the Feed Nos-Valve Assembly
No. Part names Description Reference picture
1 Feed
Nos-
Valve
Assembly
1) Separate the connector from the
Feed Nos-Valve Assembly.
2) Remove the fitting from the
Feed Nos-Valve Assembly using
a flat-head screwdriver.
3) Separate the screw from the
Feed Nos-Valve Assembly.
: THT 4X12
