Coway P-220R User Manual

Disassembling and refitting
4-2
Coway co., Ltd
4-2 Disassembling and reassembling the product
4-2-1 Disassembling the Top-Cover Assembly
No. Part names Description Reference picture
1 Water-
V
essel
Assembly
1)
Separate the Water-Vessel
Assembly by pulling it in the
direction of the arrow in the
figure.
2 Top-Cover
Assembly
1)
Separate the Top-Cover
Assembly by pulling it in the
direction of the arrow in the
figure.
2) Separate the clip of the Main
Tank-Cap Assembly.

Coway P-220R Specifications

General

Brand	Coway
Model	P-220R
Category	Water Filtration Systems
Language	English
