Coway P-220R - 4-2-2 Disassembling the Filter Assembly

Disassembling and refitting
Coway co., Ltd
4-5
4-2-2 Disassembling the Filter Assembly
No. Part names Description Reference picture
1 Filter 1)
Remove the 2 screws from the
Side-Door R Assembly.
:
2-THT 4X10
2) Separate the Auto Drain
Control-Valve using a flat-head
screwdriver and remove the
fitting from the filter.
3) Separate the filter by pulling it
in the direction of the arrow as
shown in the figure.
