Parts location diagrams
Coway co., Ltd
7-7
2 CN201
DC OUT
Pin No. Signal
1 GND
2 DC
5 V
3 GND
4 GND
5 DC
24 V
6 DC
24 V
1
CN101
AC IN
Pin No. Signal
1 220
V~
2 220
V~
7-4-2 SMPS PBA
1
2
