Coway P-220R - Disassembling the Side-Cover L Assembly

Disassembling and refitting
Coway co., Ltd
4-11
No. Part names Description Reference picture
2 Side-Cover
L
Assembly
3)
Remove the 3 screws from the
Rear Cover.
: 3-THT 4X12
4) Separate the Side-Cover L
Assembly by pulling it in the
direction of the arrow as shown
in the figure.
