C-SMART -I Pro U11er Manual
Test Wire Functional CHECK
NOTE
If the device functional CHECK is OK, then you have to proceed to the
cables functional CHECK.
Connect the test wire to the device (Fig.32).
0
0
Fig. 32 Connect the test wire
Fig.33 Test wire is ERROR
.&. CAUTION
ERROR message indicates that the test wire is not operating properly.
Please contact your local dealer or contact the factory directly for assistance.
• Insert the File clip and lip hook (or replace the lip hook with another File clip)
in the test wire.
• Connect File clip and lip clip (or a second File clip) to the contact strips on
the tester as shown on the screen(Fig. 34).
't.
0
Fig.34 Connect tester
• Cables CHECK will start automatically and the results - either OK (Fig. 35)
or ERROR (Fig. 36)- will be shown on the screen.
C-SMART ·I Pro User Manual
• Connect the motor cable to the Control unit's motor socket.
• Connect the contra angle to the motor handpiece and insert the file.
• Install the lighting device and catch the file.
• Connect the lip hook wire to the Control unit and connect the lip hook.
7.4 Changing the Battery
.&. CAUTIONS
PRECAUTIONS ON CHANGING BATTERY:
• Do not open any part other than the battery cover
• Be sure to purchase and use only the recommended battery.Otherwis e ,
battery may cause damage,fluid leakage or explode.
• Ensure that the AC adapter is disconnected and turn off before changing
the battery.
• Do not change the battery with wet hands as this may cause short-circuiting
of the battery and moisture infiltrating the device.
• The used battery must be disposed of in accordance with the local
regulations.
• Turn the power off
• Disconnect the AC adapter.
• Remove the screw from the cover with a screw driver, and remove the
battery cover.
• Insert the battery cord connector into the device connector in accordance
with the polarity indication inside the battery compartment and place the
battery into the compartment with care so as not to catch the cord.
NOTE
In case of difficulty in inserting the connector,the polarity may be incorrect.
Do not insert it by force.
• Close the battery cover and lock the screws.
•If you need to replace the battery,remove the battery and unplug the
battery connector.
.&. CAUTIONS
When removing the battery cord, make sure to hold it at the connector.
Failure to do so may damage the cord.
