Coyote C1P28 - Installation Requirements; Ventilation and Airflow Requirements; Clearance Guidelines

9
A minimum of 2 vents, but optimally 4, is required per cabinet. Each vent must be at least 20 sq.
inches and have access to outside/fresh air.
Two vents on each side will facilitate and improve airflow and ventilation.
Model Cutout Dimensions Overall Dimensions
Electrical Outlets
Needed {120V)
Grills
Height Width Depth Height Width Depth Rotisserie Lights
C1P28
16½" 26¼" 23" 31" 28" 27"
No
Qty 1
C1P36
16½" 34 ¼" 23" 31" 36" 27"
No
Qty 1
Ventilation Requirements for Proper Operation of Your Coyote Grill
• Ventilation for a pellet grill is mandatory to ensure that your grill performs as intended and that
you, your family, and your guests are safe.
• Failure to provide proper ventilation will nullify Coyote's warranty and will cause a risk of bodily
injury or death.
• If you install your grill on an island, it must be adequately ventilated. Any such island must have
a minimum of 2 vents (but optimally 4) per cabinet. Each vent must be at least 20 sq. inches and
have access to outside/fresh air. These vents allow for proper airflow to your Coyote Outdoor
Living Pellet Grill. Insufficient airflow can significantly negatively affect its performance. Low
temperatures, fluctuating temperatures, flameouts, and soot can all result from poor airflow.
• Ventilation and typical wind direction and conditions must always be considered when planning
your outdoor cooking island. Just as you would design the layout and measure your indoor
kitchen, you must do the same for the outdoors; but you cannot forget Mother Nature and the
effects she can have on your outdoor cooking equipment.
Clearance
• From Non-Combustible Materials: Coyote grills can be placed directly on or adjacent to non-
combustible materials, subject to ventilation requirements. The hood on a Coyote grill pivots
mainly on the body. Suppose you have a wall or partition behind the unit that would block
ventilation. In that case, a minimum of 7" clearance from the back of the grill to the wall is
needed for ventilation. If you do not have a wall or partition blocking the ventilation of the unit.
You only need an extra 3¼" behind the unit for the hood to open fully.
