COZY DVCF402D - Furnace Assembly Replacement Parts; Dvcf40 Xd Models

COUNTERFLOW DIRECT VENT GAS WALL HEATER 27
FURNACE ASSEMBLY REPLACEMENT PARTS
DVCF40XD MODELS
REF.
NO.
REPLACEMENT PART DESCRIPTION DVCF402D DVCF401D
1
Outer Casing with Air Pan 11C42-2 11C42-2
2
Heating Element 11C67 11C67
3
Element Tube 11C37 11C37
4
Inner Liner 11B46 11B46
5
Deflector Baffle Handle 11C63 11C63
6
Fan Shroud 11B86 11B86
7
Top Front Panel 11B102 11B102
8
Center Front Panel 11C62 11C62
9
Bottom Front Panel 11B117 11B117
10
Element Face Cover 11A103 11A103
11
Limit Switch P200300 P200300
12
Fan Switch P200200 P200200
13
Motor P151101 P151101
14
Motor Support (2 Req.) 7B46 7B46
15
Transformer P024200 P024200
16
Internal Wires (except for 4007332 / 4007331) 11A152 11A152
17
Vibration Isolator (4 Req.) P022800 P022800
18
Fan Blade P200600 P200600
19
Switch Box 11B05 11B05
20
Switch Box Cover 11C68 11C68
21
Observation Door Assembly 12B40 12B40
22
Element Face Gasket P200900 P200900
23
Air Pan Tunnel Gasket P151900 P151900
24
Seal Gasket P103100 P103100
25
KIT Venting Kit 9802 9802
26
KIT Side Outlet Kit 6701 6701
27
KIT Side Casing Grille 6702 6702
28
KIT Diffusing Grille - Two-Way 6703 6703
KIT Diffusing Grille - One-Way 6704 6704
29
Gasket, Burner Pan (2 Req.) P321020 P321020
Not
Shown
Knob P332606 P332606
Not
Shown
Thermostat 78355 78355
MODEL NUMBERS
NATURAL PROPANE
DVCF402D DVCF401D
