30 COUNTERFLOW DIRECT VENT GAS WALL HEATER
FURNACE ASSEMBLY REPLACEMENT PARTS
DVCF60XD MODELS
REF.
NO.
REPLACEMENT PART DESCRIPTION DVCF602D DVCF601D
1
Outer Casing with Air Pan 11C42-1 11C42-1
2
Air Pan Tunnel Gasket P151900 P151900
3
Inner Liner 11B120 11B120
4
Heating Element 11C66 11C66
5
Observation Door Assembly 12B40 12B40
6
Burner Pan Gasket (2 Req.) P321020 P321020
7
Bottom Front Panel 11B103 11B103
8
Center Front Panel 11C59 11C59
9
Bottom Air Deflector 11B123 11B123
10
Center Air Deflector 11B119 11B119
11
Selector Switch P200400 P200400
12
Fan Switch P200200 P200200
13
Switch Box Cover 11C68 11C68
14
Switch Box 11B05 11B05
15
Seal Gasket P103100 P103100
16
Element Baffle 11B116 11B116
17
Limit Switch P321942 P321942
18
Top Air Deflector 11B119 11B119
19
Top Front Panel 11B102 11B102
20
Fan Shroud 11B86 11B86
21
Element Face Gasket P304000 P304000
22
Fan Blade P200600 P200600
23
Motor P321601 P321601
24
Motor Support (2 Req.) 7B46 7B46
25
Vibration Isolator (4 Req.) P022800 P022800
26
Transformer P024200 P024200
27
Internal Wires 6007732 6007731
28
Element Tube 11C37 11C37
29
KIT Venting Kit 9809 9809
30
KIT Side Outlet Kit 6701 6701
31
KIT Side Casing Grille 6702 6702
MODEL NUMBERS
NATURAL PROPANE
DVCF602D DVCF601D
