COZY DVCF403C-H - Parts

1018028-A
Page 21
NOTE: Parts & schematic drawings on current models are shown at: cozyheaters.com | Specications subject to change without notice.
PART DESCRIPTION
REF.#
PART NO. PART NO. PART NO. PART NO.
Propane Gas Model Numbers ........................
Natural Gas Model Numbers .........................
DVCF404C-H DVCF408C-H DVCF554C-H DVCF558C-H
DVCF403C-H DVCF407C-H DVCF553C-H DVCF557C-H
 1A CasingSide, Right 34065 34065 34560 34560
1B CasingSide, Left 34055 34055 34550 34550
1C CenterFrontPanelAssembly 34104 34104 30534 30534
1D TopAssembly 34050 34050 34050 34050
1E UpperBackAssembly 34080 34080 34080 34080
 1F LowerBackAssembly 34090 34090 34575 34575
1G BottomAssembly 34070 34070 34070 34070
N/A CasingMountingBrackets *30260 *30260 *30260 *30260
2 LinerAssembly 34115 34115 34600 34600
3 FanShroudAssembly 34140 34140 34140 34140
 4 TopLouver 34100 34100 34590 34590
6 BottomLouverAssembly 30100 30100 30100 30100
7 UpperFrontShield 30250 30250 30250 30250
8 SwitchBox 30252 30252 30252 30252
9 SwitchBoxCover 30253 30253 30253 30253
 10 LowerFrontShield 30256 30256 30256 30256
 11 MotorMountingBracket *34088 *34088 *34579 *34579
 16 FanMotor 72108 72108 72110 72110
 17 FanBlade, Dynacone 72111 72111 72111 72111
 18 RubberGrommet (Requires 4) **78010 **78010 **78010 **78010
 19 LimitSwitch, 60T11-L220F N/A N/A 72160 72160
 19 LimitSwitch, 60T11-L180F 78065 78065 N/A N/A
 20 FanSwitch, 60T12 F110 Degree 78064 78064 78064 78064
 22 Aux.LimitSwitch, 60T15-L350 78086 78086 78086 78086
 24 Transformer 78069 78069 78069 78069
 N/A TransformerPlate 34089 34089 34089 34089
 26 CozyHandle 84003 84003 84003 84003
30 Wiring Harness 72251 72252 72253 72250
35 TerminalBoard 78300 78300 78300 78300
 36 FlueOutletPipeGasket-7”Circle 72055 72055 72055 72055
 38 HeatExchangerCoverPlateGasket-7x6” 72053 72053 72053 72053
39 BurnerBoxInletGasket-11-1/2x5”(AirBox) 72052 72052 72052 72052
 44 HeatExchangerKit 34805 34805 34815 34815
 50 SlipJointAssemblyw/Gaskets 34220 34220 34220 34220
 51 AirDropAssembly 34201 34201 34630 34630
52 HeatExchangerCoverPlate 34195 34195 34195 34195
 61 SlipJointRingGasket-9-1/2”Circle 72056 72056 72056 72056
N/A SlipJointGasket-3-1/2x7 72057 72057 72057 72057
 N/A SlipJt.RingGsk.(2pc.Graphite)3-3/4x7-1/2” 72058 72058 72058 72058
* Requires 2 ** Requires 4
DIRECT VENT COUNTERFLOW WALL FURNACE PARTS LIST
Natural Gas: DVCF403C-H, DVCF553C-H, DVCF407C-H, DVCF557C-H
Propane Gas: DVCF404C-H, DVCF554C-H, DVCF408C-H, DVCF558C-H
